70M-OAC24
I/O Module Relays Output Module 120VAC 4000Vrms Thru-Hole ...
DESCRIPTION
The 70M-OAC24 is a miniature AC output module manufactured by Grayhill designed for switching AC loads with zero-crossing turn-on capability and 24 VDC logic control. The module operates with a nominal line voltage of 240 VAC and supports load voltage ranges from 24 to 280 VAC, with a load current range of 0.03 to 3.0 A rms and a maximum 1-cycle surge rating of 80 A rms. It features optical isolation with 4000 V rms isolation voltage, a static dv/dt rating of 3000 V/µsec, and turn-on/turn-off times of 8.33 ms at 60 Hz. The module incorporates transient protection meeting IEEE 472 surge withstanding requirements, a built-in status LED, SPST normally open contact configuration, and is UL, CSA, CE, and TÜV certified. Operating across -40 to 100 °C with a lifetime warranty, the 70M-OAC24 is ideal for industrial control systems, HVAC applications, and automated load switching where reliable AC power management and logic-level control integration are required.
Mots-clés de recherche: 70MOAC24
SPÉCIFICATIONS
EN STOCK: 0
sur commande:
100
Peut expédier 12/10/26
Quantité minimale de commande pour qté en stock: 5
Quantité minimale de commande pour qté en rupture de stock: 25
DÉLAI DE L'USINE 8 Semaines
Prix (CAD)
Outils/Modèles 3D
ressources
Fiche technique
