M80-337 by harwin

M80-337

Harwin

The M80-337 is a Datamate Mix-Tek male straight solder power contact designed for 16 AWG wire. ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The M80-337 is a male straight solder power contact from the Datamate Mix-Tek series, specifically designed for 16 AWG wire. It supports a current rating of 10A and has a maximum contact resistance of 6mΩ. The contact is constructed with a gold-plated copper alloy body and a nickel-plated beryllium copper latching collar for robust performance. Rated for 500 mating cycles and an operating temperature range of -55°C to +125°C, this component provides a durable and reliable power connection for various electronic systems.

Search Keywords: M80337

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Harwin
Référence:
M80-337
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
GB
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10

EN STOCK: 270

Peut être expédié immédiatement

Commande min Quantitè: 10

Multiple: 10

DÉLAI DE L'USINE 6 Weeks

PRICE (USD)

QTÉ
Prix unitaire
10
$8.69
30
$8.42
50
$8.04
100
$7.81
250
$7.37
500
$7.18
1 000 +
$7.09
Emballage standard du fournisseur
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
