22AC2 by honeywell
Image non contractuelle - consultez les spécifications du fabricant

22AC2

Honeywell

MICRO SWITCH™ Basic Switches: AC Series, Door Switch, Single Pole Double Throw (SPDT), 15 A at 250 Vac, Rod Actuator, Silver Contacts, Screw Termination ...

Fiche technique
RoHS Compliant
Box Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

The Honeywell 22AC2 safety interlock switch offers a choice of momentary, maintained or pull-to-cheat actuation. It automatically cuts power when the service door or drawer is opened. The Honeywell switch is available with one or two SPDT switches and has a wide electrical rating of 5 A to 25 A.

Safety interlock switch, also known as a micro switch is a kind of momentary contact switch. They enable circuit testing by manually pulling the rod actuator to the maintained-ON position, which is then reset when the door is closed. They are used in appliances, office equipment, test instruments, computer and business equipment, vending machines, communications equipment, HVAC equipment and medical and dental equipment.

Points forts du produit:

  • Available with one or two SPDT switches
  • UL recognized versions available
  • Choice of termination
  • Automatically cuts power when service door or drawer is opened
  • Choice of momentary, maintained or pull-to-cheat actuation
  • Versatile mounting bracket for side or end mounting
  • Current rating ranges from 5 A to 25 A

Potential Applications:

  • Appliances
  • Vending machines
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment

Search Keywords: 22AC2

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Honeywell
Référence:
22AC2
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Box
Type:
Door Interlock
Style d'actionneur:
Rod
Configuration pôles-directions:
SPDT
Courant nominal maximal:
15@250VAC A
Type de borne:
Screw
Température de fonctionnement:
-53 to 82 °C
Indice de protection IP:
N/A
Configuration de l'interrupteur:
N.O./N.C.
Orientation du corps:
Straight
  Possible Replacement options available.  See Alternatives

EN STOCK: 424

Peut être expédié immédiatement

sur commande: 2 000   Peut expédier 10/5/26

DÉLAI DE L'USINE 12 Weeks
