26PC05SMT by honeywell
Image non contractuelle - consultez les spécifications du fabricant

26PC05SMT

Honeywell

Honeywell Miniature SMT Low Pressure Sensors: 26PC Series, Wet/Wet Differential Sensing, Compensated/Unamplified, 5 psi Pressure Range, Port 1: Standard Configuration, Port 2: Standard Configuration ...

Fiche technique
RoHS Compliant
Tube Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

26PC05SMT Board Mount Pressure Sensor from Honeywell comes with alignment pins for position accuracy. The SMT series pressure sensors are small and low cost, but deliver high value. The design flexibility of this Differential Pressure Sensor reduces installation costs and eliminates secondary operations by enabling it to be used with other SMT components on a PCB.

A pressure sensor is an electromechanical pressure-sensing device which detects the pressure applied and converts it into an electrical signal. Board Mount Pressure Sensors are designed for various industrial and mechanical applications that perform according to the changing pressure. Honeywell Sensors are widely used in medical, industrial and environmental applications like Continuous Positive Airway Pressure equipment, blood glucose monitors, oxygen conservers, residential fuel cells, and soft drink dispensing, etc.

Points forts du produit:

  • Maximum peak reflow temperature of 260 °C [500 °F]
  • Gage, vacuum gage, differential gage, wet/wet differential sensing available in one package
  • Proven elastomeric interconnections of the 20PC family
  • Temperature compensation
  • End point calibration
  • Sensor consists of only five components
  • Elastomeric construction
  • Wide operating temperature range of -40 °C to 85 °C [-40 °F to 185 °F]
  • Alignment pins for position accuracy
  • Small package size (less than one half the size of the 26PC) and compact surface mount profile
  • True wet/wet differential sensing

Search Keywords: 26PC05SMT

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Honeywell
Référence:
26PC05SMT
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
90262000
COO:
CN
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tube
Montage:
PCB Surface Mount
Précision:
±0.5 %
Type de pression du dispositif:
Differential
Plage de Pression de Fonctionnement:
0 to 5 psi
Fluide:
Air,Gas,Liquid
Tension de sortie:
0 to 50 mV
Temps de réponse:
1 mS
Tension d'alimentation de fonctionnement typique:
10 V
Température de fonctionnement:
-40 to 85 °C
Dimension:
10.92 x 6.1 x 7.87 mm

EN STOCK: 291

Peut être expédié immédiatement

DÉLAI DE L'USINE 12 Weeks

Prix (USD)

QTÉ
Prix unitaire
1
$105.05
5
$98.84
10
$94.12
20
$92.06
50
$91.48
100 +
$91.26
Emballage standard du fournisseur
Log in for special pricing Cliquez pour demander un devis Price Match Request
