3LS1 by honeywell
Image non contractuelle - consultez les spécifications du fabricant
Honeywell Distributeur agréé

3LS1

MICRO SWITCH™ General Purpose Limit Switches: LS Series, Epoxy-Coated Zinc Housing, Non Plug-in Body Style, Side Roller Plunger, Ø 16,7 mm x 4,8 mm [0.66 in x 0.19 in] SST Roller, Roller Plunger May Be Locked in Any Position Through 360°, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, 10 A 120, 240, or 480 Vac, 0.5 in - 14 NPT Conduit, Operating Temperature: -29 °C to 71 °C [-20 °F to 160 °F], NEMA 1, 3, 4, 6 and 13 ...

Voir la fiche technique Interroger la fiche technique
Conforme RoHS
Emballage
ACCESSOIRES
Certificat de conformité

DESCRIPTION

The HONEYWELL part 3LS1 is a MICRO SWITCH„¢ General Purpose Limit Switch that features an epoxy-coated zinc housing and a non-plug-in body style. It has a side roller plunger with a diameter of 16.7 mm and a thickness of 4.8 mm. The switch is equipped with a stainless steel roller with a diameter of 0.66 in and a thickness of 0.19 in.The unique design of this limit switch allows the roller plunger to be locked in any position through 360°, providing versatility in various applications. It has a 1NC 1NO single pole double throw (SPDT) snap action, double break configuration.With a current rating of 10 A and voltage options of 120, 240, or 480 Vac, this switch is capable of handling a wide range of electrical loads. It features a 0.5 in - 14 NPT conduit for easy installation and is designed to operate in temperatures ranging from -29 °C to 71 °C (-20 °F to 160 °F).The 3LS1 limit switch has a NEMA 1, 3, 4, 6, and 13 rating, making it suitable for use in various indoor and outdoor environments. It is a reliable and durable solution for applications that require accurate and dependable position sensing.

Points forts du produit:

  • Mode of operation is field adjustable
  • NEMA 1, 3, 4, 6, and 13
  • Wide choice of heads and actuators
  • Variety of operating characteristics
  • Captive screws
  • UL and CSA approved parts available

Applications potentielles:

  • Machine tools
  • Conveyors
  • Material handling
  • Metal fabrication equipment
  • Lift trucks

Mots-clés de recherche: 3LS1

SPÉCIFICATIONS

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Honeywell
Référence:
3LS1
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Conditionnement standard du fournisseur: Ces informations sont fournies aux clients qui préfèrent acheter par multiples de la quantité d
10
Type:
Enclosed
Style d'actionneur:
Side Roller Plunger
Configuration pôles-directions:
SPDT
Configuration de l'interrupteur:
N.O./N.C.
Force de fonctionnement:
40.03 N
Dimension:
39.88 x 70.33 x 93.98 mm
Courant nominal maximal:
0.8@115VDC A
Type de borne:
Conduit
Norme NEMA comme indice de protection du boîtier:
1, 3, 4, 6, 13
Orientation du corps:
Right Angle

EN STOCK: 9

Peut être expédié immédiatement

sur commande: 25   Peut expédier 12/2/26

DÉLAI DE L'USINE 40 Semaines

Prix (USD)

QTÉ
Prix unitaire
1
$421.90
3
$417.80
5 +
$405.20
