LW1B-M1C5-G
Switch Push Button N.O./N.C. SPDT Flush Round Button 3A 250VAC 125VDC Momentary Contact Quick Connect/Solder Panel Mount ...
DESCRIPTION
The LW1B-M1C5-G is an illuminated pushbutton switch from IDEC's LW Series Flush Silhouette Switches, featuring a round flush design with black plastic bezel and momentary operation. It is configured with silver contacts in a DPDT (double-pole double-throw) contact form, providing dual independent switching circuits. The switch is rated for AC operation at 125 V with 2 A resistive load and 2 A inductive load (50/60 Hz, PF 0.6–0.7), and DC operation at 30 V with 2 A resistive load and 1 A inductive load (L/R = 7 ms max). Contact material is silver with a maximum contact resistance of 50 mO and insulation resistance of 100 MO minimum (500 V DC megger). The switch operates reliably across -25 °C to +50 °C (illuminated units) and is suitable for industrial control panels, machinery interfaces, and automation systems requiring dual-circuit momentary switching with visual feedback.
Mots-clés de recherche: LW1BM1C5G
SPÉCIFICATIONS
EN STOCK: 0
sur commande:
30
Peut expédier 9/4/26
DÉLAI DE L'USINE 12 Semaines
Prix (USD)
Outils/Modèles 3D
CAD Drawing
Fiche technique
Catalog
Learn more about IDEC Switches, Pilot Lights and E-Stops
