DCMM-8W8S
D Subminiature Connector - 8 Contact - Female - Solder Terminal - Hole .112-.124 - Socket ...
DESCRIPTION
The DCMM-8W8S is a D-Subminiature connector from the Combo D Series designed for mixed-layout applications requiring flexible contact arrangements. It features a contact arrangement of 8W8 (8 empty size 8 cavities) with support for wire gauges ranging from AWG 8 to AWG 26, accommodating both signal and power connections. The connector is rated for a maximum signal current of 7.5 A per contact with a contact resistance of 10 mO maximum, and provides a dielectric withstanding voltage of 500 VAC at sea level. Operating reliably across a temperature range of -55°C to +150°C with 500 mating cycles, this connector is well-suited for industrial control systems, aerospace applications, and harsh environment installations where robust interconnection and thermal stability are essential.
Mots-clés de recherche: DCMM8W8S
SPÉCIFICATIONS
EN STOCK: 416
Peut être expédié immédiatement
Quantité minimale de commande: 5
DÉLAI DE L'USINE 16 Semaines
Prix (CAD)
Outils/Modèles 3D
ressources
Fiche technique
