1101M2S4AV2BE2
Miniature Slide Switch ...
DESCRIPTION
The 1101M2S4AV2BE2 is a miniature slide switch from the 1000 Series, designed for low-level switching applications in test & measurement equipment, telecommunications, and computer peripherals. This SPDT switch features vertical actuation with right-angle PC thru-hole termination at 0.150" pitch, epoxy terminal seal compatible with bottom-wash cleaning, and gold-plated contacts for reliable low-level/dry circuit operation. The switch operates over a temperature range of -30°C to 65°C with contact resistance below 10 mO typical at 2–4 V DC and 100 mA, and maintains insulation resistance of 10? O minimum with dielectric strength of 1,000 Vrms minimum at sea level. With 100,000 make-and-break cycles at full load and RoHS compliance, this switch is ideal for applications requiring compact, reliable switching in space-constrained environments.
Mots-clés de recherche: 1101M2S4AV2BE2
SPÉCIFICATIONS
EN STOCK: 169
Peut être expédié immédiatement
Quantité minimale de commande pour qté en stock: 5
Quantité minimale de commande pour qté en rupture de stock: 80
DÉLAI DE L'USINE 8 Semaines
Prix (CAD)
Outils/Modèles 3D
Product Drawing
Fiche technique
