DESCRIPTION
SDA01H1BD is a single-position low-profile DIP switch from the SDA Series featuring an extended actuator design and thru-hole terminals without top tape seal. The switch is rated for 25 mA @ 24 V DC or 100 mA @ 5 V DC, with a contact resistance of 50 mO maximum and an insulation resistance of 100 MO between terminals. It offers a dielectric withstanding voltage of 300 V DC minimum for 1 minute, mechanical and electrical life of 1,000 cycles at rated loads, and operates reliably across a temperature range of -40°C to +85°C. The switch features a low-profile design that saves space, gold-plated beryllium copper contacts, and is RoHS compliant, making it ideal for address switching in industrial controls, logic switching for computers and peripherals, and general function control applications.
Mots-clés de recherche: SDA01H1BD
SPÉCIFICATIONS
EN STOCK: 2 150
Expédition today, Saisissez la valeur du paramètre.
Quantité minimale de commande pour qté en stock: 65
Quantité minimale de commande pour qté en rupture de stock: 65
DÉLAI DE L'USINE 19 Semaines
Product Drawing
Fiche technique
