Image non contractuelle - consultez les spécifications du fabricant

PF-27N25WQ

Name: PF-27N25WQ
Brand: Mallory Sonalert
SKU: 11715994
Price: 68.35 USD
Availability: InStock

Mallory Sonalert

The PF-27N25WQ is a panel-mount audio indicator that produces a fast pulsed tone at a frequency of 2500 Hz. ...

Fiche technique

RoHS Compliant

DESCRIPTION

The PF-27N25WQ is an electronic audio indicator designed to provide a clear audible signal. It operates over a wide voltage range of 3 to 28 VDC, with a rated voltage of 12 VDC, and produces a minimum sound pressure level of 90 dB at 30 cm. This device features an oscillation frequency of 2500 Â±500 Hz and a fast pulse rate of 3.0 Hz, while consuming a maximum of 15 mA at its rated voltage. Housed in black ABS plastic and equipped with 28 AWG lead wires, it is built to function reliably in temperatures from -20Â°C to +70Â°C. The PF-27N25WQ is suitable for various applications requiring a distinct audible alert, such as in control panels, alarm systems, and electronic equipment.

Points forts du produit:

Potential Applications:

Search Keywords: PF27N25WQ

SPÉCIFICATION

Attribut du produit

Valeur de l'attribut

Sélectionner un attribut

Produits trouvés : 0

fournisseur:

Mallory Sonalert

Référence:

PF-27N25WQ

Unité de mesure:

Par Each

RoHS:

Yes

HTS:

8531809041

COO:

ECCN:

EAR99

Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
