MCP4822-E/SN by microchip technology
Image non contractuelle - consultez les spécifications du fabricant

MCP4822-E/SN

Microchip Technology

DAC - 12 bit - Serial - 2.7V to 5.5V - SOIC - 8 Pins. ...

Fiche technique
RoHS Compliant
TUBE Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

The MCP4822-E/SN is a dual channel, 12bit voltage output DAC (Digital to Analogue Converter) with internal voltage reference in 8 pin NSOIC package. The device has high precision internal voltage reference (VREF = 2.048V). The user can configure full scale range of device to be 2.048V or 4.096V by setting gain selection option bit (gain of 1 of 2). Each DAC channel can be operated in active or shutdown mode individually by setting configuration register bits. In shutdown mode, most of internal circuits in shutdown channel are turned off for power savings and output amplifier is configured to present a known high resistance output load (500Kohm typical). The MCP4822-E/SN provides high accuracy and low noise performance. The devices utilize resistive string architecture with its inherent advantages of low DNL error, low ratio metric temperature coefficient and fast settling time.

Search Keywords: MCP4822ESN

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Microchip Technology
Référence:
MCP4822-E/SN
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8542390040
COO:
TH
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Tension d'alimentation double maximale:
N/R
Type de convertisseur:
General Purpose
Type d'Interface Numérique:
Serial (3-Wire, SPI, Microwire)
Famille:
MCP4822
Taux de conversion:
N/A
Architecture:
Resistor-String
Dimension:
4.9 x 3.9 x 1.25(Min) mm
Erreur de non-linéarité intégrale:
±12 LSB
Prise en Charge de l'Alimentation Numérique:
No
Erreur de pleine échelle:
±2 %
  Different packaging options available.  See Alternatives

EN STOCK: 1,861

Peut être expédié immédiatement

sur commande: 2 000   Peut expédier 7/27/26

Commande min Quantitè: 10

DÉLAI DE L'USINE 10 Weeks

Prix (USD)

QTÉ
Prix unitaire
10
$3.87
50
$3.41
100
$3.05
300
$3.03
500
$3.02
1 000
$3.01
2 500
$3.00
5 000 +
$2.99
Emballage standard du fournisseur
