PIC12F675-I/SN
MCU 8 Bit - Flash - PIC12 Family PIC12F6xx Series Microcontrollers - 20 MHz - 1.75 KB - 64 Byte - 8 Pins. ...
DESCRIPTION
The PIC12F675-I/SN is a 8-bit flash-based CMOS Microcontroller. The easy-to-program (only 35 single word instructions) CMOS Flash-based 8-bit microcontroller packs Microchip's powerful PIC® MCU architecture into an 8-pin package and features 4 channels for the10-bit Analogue-to-Digital (A/D) converter, 1-channel comparator and 128bytes of EEPROM data memory. The data memory is partitioned into two banks, which contain the general purpose registers and the special function registers. The special function registers are located in the first 32 locations of each bank. Register locations 20h-5Fh are general purpose registers, implemented as static RAM and are mapped across both banks. All other RAM is unimplemented and returns 0 when read. RP0 (STATUS<5>) is the bank select bit.
Mots-clés de recherche: PIC12F675ISN
SPÉCIFICATIONS
EN STOCK: 0
sur commande:
2 000
Peut expédier 12/14/26
Quantité minimale de commande: 100
Ce modèle de message est utilisé pour informer un affilié qu'une certaine commande a été payée. La commande obtient le statut Payée lorsque le montant a été débité.: 100
DÉLAI DE L'USINE 17 Semaines
Prix (CAD)
Outils/Modèles 3D
ressources
Fiche technique
