NLT4FP by neutrik
Image non contractuelle - consultez les spécifications du fabricant

NLT4FP

NEUTRIK

STX Series - 4 pole female chassis connector - metall housing - solder contacts The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Series featu ...

RoHS Compliant
Emballage
ACCESSOIRES
Arrêté
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

4 pole female chassis connector, metal housing, solder contacts

The new STX Series is the next generation of 4 pole speakON connectors especially designed for amplifier-loudspeaker applications in harsh and demanding environments such as professional touring. The extremely rugged and durable STX Series feature an all metal housing and a built-in gasket providing weatherproof protection to IP54. The 4 pole version is now available as 4 gender system including male cable and female chassis connector.

Points forts du produit:

  • Current rating 40 Amp continuous, 50 Amp audio with 50% duty cycle
  • Robust and durable all metal housing
  • Sealing ring provides weatherproof IP54 rating
  • Reinforced metal quick lock system for ease and precise locking
  • Extra large solder contacts for up to 6mm² (AWG10) wires
  • Mate with all available Speakon products

Search Keywords: NLT4FP

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
NEUTRIK
Référence:
NLT4FP
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8536694030
COO:
LI
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Type:
Loudspeaker Connector
Genre:
F
Orientation du corps:
Straight
Montage:
Panel Mount
Matériau du boîtier:
Zinc Die Cast
Nombre de contacts:
4
Placage des contacts:
Silver
Méthode de terminaison:
Solder
Température de fonctionnement:
-30 to 80 °C
Life Cycle:
Arrêté
   This product is not in stock and cannot be back-ordered
  Possible Replacement options available.  See Alternatives
