G3VM-351A

Name: G3VM-351A
Brand: Omron Electronics
SKU: 12048578
Price: 69.2 USD
Availability: InStock

The G3VM-351A is a general-purpose, single-pole single-throw normally open (SPST-NO) MOS FET relay in a 4-pin DIP package, capable of switching loads up to 350V. ...

Voir la fiche technique Interroger la fiche technique

Conforme RoHS

Arrêté et remplacé

Certificat de conformité

DESCRIPTION

The G3VM-351A is a general-purpose, 1a (SPST-NO) MOS FET relay in a 4-pin DIP package designed for a wide range of switching applications. It features a high load voltage of 350V and can handle a continuous load current of 120 mA. This relay has a maximum ON-state resistance of 50 Ω, a typical turn-on time of 0.3 ms, and provides a high dielectric strength of 2,500 Vrms between the input and output. Its robust operating temperature range of -40°C to +85°C makes it suitable for demanding environments such as communication equipment, test and measurement systems, and industrial controls.

Points forts du produit:

Applications potentielles:

Mots-clés de recherche: G3VM351A
