SZNUD3124DMT1G
The SZNUD3124DMT1G is an AEC-Q101 qualified automotive inductive load driver designed to switch loads such as relays, solenoids, and small DC motors. ...
DESCRIPTION
The SZNUD3124DMT1G is a micro-integrated inductive load driver designed as a single-component solution for switching inductive loads in automotive and industrial environments. It is capable of driving relay coils rated up to 150 mA at 12 V and accepts logic level inputs, allowing it to be driven by devices like microcontrollers. The device features an internal Zener diode, which eliminates the need for an external free-wheeling diode, thereby simplifying circuit design and reducing PCB layout complexity. With a continuous drain-to-source voltage rating of 28 V and a wide operating temperature range, it provides a robust interface between sensitive logic and DC relay coils. As an AEC-Q101 qualified and PPAP capable component in an SC-74 package, it is ideal for applications such as driving window, latch, door, and antenna relays.
Mots-clés de recherche: SZNUD3124DMT1G
SPÉCIFICATIONS
EN STOCK: 31 550
Peut être expédié immédiatement
Quantité minimale de commande: 100
DÉLAI DE L'USINE 39 Semaines
Prix (CAD)
Fiche technique
Product Change Notification
