1706714
PCB terminal block - nominal current: 16 A - rated voltage (III/2): 400 V - nominal cross section: 1.5 mm² - pitch: 5.08 mm - number of positions: 1 - connection method: Spring-cage connection - mounting: Wave soldering - conductor/PCB connection direction: 45 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm. Single module for the custom grouping of different numbers of positions. An end terminal block is also needed to terminate the block (see accessories). Blocked items with different numbers of positions are also available. ...
DESCRIPTION
The PHOENIX CONTACT part 1706714 is a PCB terminal block with a nominal current of 16 A and a rated voltage of 400 V. It has a nominal cross section of 1.5 mm² and a pitch of 5.08 mm. This terminal block has 1 position and features a spring-cage connection for easy and secure wire termination. It is designed for wave soldering mounting and has a 45 ° conductor/PCB connection direction. The terminal block is available in a green color and has a linear pinning pin layout. The solder pin has a length of 3.5 mm. This single module allows for custom grouping of different numbers of positions. An end terminal block is required to terminate the block, which can be found in the accessories. Additionally, blocked items with different numbers of positions are also available for convenience.
Mots-clés de recherche: 1706714
SPÉCIFICATIONS
EN STOCK: 1 800
Expédition today, Saisissez la valeur du paramètre.
sur commande:
1 000
Peut expédier 10/28/26
Quantité minimale de commande: 250
Ce modèle de message est utilisé pour informer un affilié qu'une certaine commande a été payée. La commande obtient le statut Payée lorsque le montant a été débité.: 250
DÉLAI DE L'USINE 12 Semaines
Prix (USD)
Outils/Modèles 3D
ressources
Fiche technique
PCN - 01-Jan-2015 - INTRODUCTION OF 2D BARCODING
