1829345 by phoenix contact
Image is representational - see mfr. specs

1829345

Phoenix Contact

Feed-through header - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 2 - pitch: 3.81 mm - connection method: Solder/Slip-on connection - color: green - contact surface: Tin - mounting: Direct mounting - pin layout: Linear pinning - solder pin [P]: 9.4 mm ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1829345 is a feed-through header designed for reliable electrical connections. It has a nominal current rating of 8 A and a rated voltage of 160 V. The header features a 1.5 mm² nominal cross section and comes with 2 positions and a 3.81 mm pitch. The connection method is solder/slip-on, ensuring secure and efficient connections. The header is color-coded green and has a tin contact surface. It can be directly mounted for easy installation. The pin layout is linear, with a solder pin spacing of 9.4 mm. Overall, this feed-through header offers robust performance and is a reliable choice for various electrical applications.

Search Keywords: 1829345

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Phoenix Contact
Référence:
1829345
Alias/AKA:
1829345
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
PL
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Panel Mount
Pitch:
3.81 mm
Number of Contacts:
2
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

EN STOCK: 240

Peut être expédié immédiatement

Commande min Quantitè: 50

Multiple: 50

DÉLAI DE L'USINE 4 Weeks

PRICE (USD)

QTÉ
Prix unitaire
50
$3.56
100
$3.48
250
$3.41
500
$3.37
1 000
$3.32
2 500
$3.31
5 000 +
$3.30
Emballage standard du fournisseur
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

ressources

ACCESSOIRES

0710015

Screw set - for securing the header to the housing wall - consists of M2 x 8 screw - sprin ...

0804109

Marker card - Card - white - labeled - Horizontal: consecutive numbers 1 ... 10 - 11 ... 2 ...

1205037

Screwdriver - slot-headed - VDE insulated - size: 0.4 x 2.5 x 80 mm - 2-component grip - w ...

1734634

Coding profile - is inserted into the slot on the plug or inverted header - red insulating ...
