3044102 by phoenix contact
Image is representational - see mfr. specs

3044102

Phoenix Contact

Feed-through terminal block - nom. voltage: 1000 V - nominal current: 32 A - connection method: Screw connection - number of connections: 2 - cross section: 0.14 mm² - 6 mm² - AWG: 26 - 10 - width: 6.2 mm - height: 46.9 mm - color: gray - mounting type: NS 35/7,5 - NS 35/15 ...

RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3044102 is a 2-position 1-level grey Feed-through Terminal Block with a polyamide insulator, the M3 screw connection and NS 35/7,5, NS 35/15 mounting. This UT 4 terminal block has large wiring space enables the connection of solid and stranded conductors without ferrules, even above the nominal cross section. The cable entry funnel enables the use of conductors with ferrules and plastic collars within the nominal cross section. It accepts 26 to 10AWG wire range. Multi-conductor connection offers maximum flexibility and wiring density Optimum screwdriver guidance through closed screw shafts Half-sine shock form 9mm Stripping length UL94V-0 Flammability rating Applications Industrial, Automation & Process Control

Search Keywords: 3044102

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Phoenix Contact
Référence:
3044102
Alias/AKA:
3044102
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Body Orientation:
Straight

EN STOCK: 13,731

Peut être expédié immédiatement

Commande min Quantitè: 20

DÉLAI DE L'USINE 3 Weeks

PRICE (USD)

QTÉ
Prix unitaire
20
$1.08
50 +
$1.03
