Q2-F3X-1/8-01-MS100FT
The Q2-F3X-1/8-01-MS100FT is a flexible, flame-retardant polyolefin heat shrink tubing with a 3:1 shrink ratio designed for electrical insulation and mechanical protection. ...
DESCRIPTION
The Q2-F3X-1/8-01-MS100FT is a highly flexible, flame-retardant polyolefin heat shrink tubing. This 1/8-inch tubing features a 3:1 shrink ratio, reducing from a minimum supplied inside diameter of 3.2 mm to a maximum recovered diameter of 1.0 mm with a final wall thickness of 0.55 mm. It is rated for an operating temperature range of -55°C to +135°C and begins to shrink at 70°C. Key electrical properties include a dielectric strength over 20 kV/mm and a 600V rating. Due to its high flexibility and shrink ratio, it is ideal for electrical insulation, bundling, marking, and providing mechanical and corrosion protection, especially over irregular shapes.
Mots-clés de recherche: Q2F3X1801MS100FT
SPÉCIFICATIONS
EN STOCK: 90 Spools
Expédition today, Saisissez la valeur du paramètre.
Quantité minimale de commande: 5 Spools
Multiple: 5 Spools
DÉLAI DE L'USINE 25 Semaines
Fiche technique
