RAC04-15SGB
RECOMThe RAC04-15SGB is a 4W PCB-mount AC/DC converter that provides a regulated 15VDC output from a universal 85-305VAC input. ...
DESCRIPTION
The RAC04-15SGB is a 4W regulated AC/DC power supply from the RAC04-GA series, designed for compact, board-level industrial applications. It operates over a universal input range of 85-305VAC and delivers a single 15VDC output at up to 270mA with a typical efficiency of 78%. Key features include a wide operating temperature range of -40°C to +85°C, low no-load power consumption under 75mW, and 3kVAC reinforced isolation. The module incorporates continuous short-circuit, over-current, and over-voltage protection and is certified to multiple safety standards, including IEC/EN/UL60950. Its compact size and built-in Class A EMC filter make it ideal for space-constrained industrial and household electronics.
Search Keywords: RAC0415SGB
SPÉCIFICATION
EN STOCK: 20
Peut être expédié immédiatement
Commande min Quantitè: 20
Multiple: 20
DÉLAI DE L'USINE 14 Weeks
Fiche technique
