782XDXH10-24D by schneider electric-legacy relays
Image non contractuelle - consultez les spécifications du fabricant

782XDXH10-24D

Schneider Electric-Legacy Relays

Hermetically sealed plug-in relays - SE Relays - 3A - 4 CO - 24VDC ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

The Magnecraft / Schneider Electric 782XDXH10-24D is a high-quality electromechanical relay with a 24VDC coil voltage. This relay has a low resistance of 650Ohm, allowing for efficient and reliable operation. With its 4PDT (4 Form C) configuration, it provides versatile switching options for various applications. The relay is designed to handle a current rating of 3A, making it suitable for both low and moderate power circuits. Its plug-in control design allows for easy installation and replacement. Whether used in industrial automation, HVAC systems, or control panels, this relay offers exceptional performance, durability, and flexibility.

Search Keywords: 782XDXH1024D

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
Schneider Electric-Legacy Relays
Référence:
782XDXH10-24D
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8536410020
COO:
CN
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Construction du relais:
Non-Latching
Tension de bobine AC:
N/A
Tension de bobine DC:
24 V
Disposition des contacts:
4PDT
Courant nominal maximal:
3 A
Montage:
Connector
Style de terminaison:
Quick Connect
Bouton de test:
No
Indicateur LED:
No
Température de fonctionnement:
N/A
Résistance de bobine:
650 Ohm

EN STOCK: 221

Peut être expédié immédiatement

sur commande: 86   Peut expédier 8/27/26

DÉLAI DE L'USINE 2 Weeks

Prix (USD)

QTÉ
Prix unitaire
1
$148.53
5
$145.63
10
$121.62
20
$120.88
50
$119.06
100 +
$118.76
Emballage standard du fournisseur
Log in for special pricing Cliquez pour demander un devis Price Match Request

Outils/Modèles 3D

ressources

ACCESSOIRES

70-461-1

Socket - SE Relays - 10A - 14 pins - screw clamp terminals - mixed contact - for 782H / 79 ...

70-782D14-1

Socket - Harmony Electromechanical Relays - for 782 relays - 4PDT - 14 pins - screws clamp ...

70-782EL14-1

Socket - SE Relays - 10A - 17 pins - screw connectors - separate contact - for 782 relays

70-782E14-1

Socket - SE Relays - 10A - 17 pins - screw connectors - mixed contact - for 782 relays

Show 2 More
