NR8040T220M by taiyo yuden
Image is representational - see mfr. specs

NR8040T220M

Taiyo Yuden

Inductor Power Shielded Wirewound 22uH 20% 100KHz Ferrite 2.2A 0.0858Ohm DCR 3131 T/R ...

Fiche technique
RoHS Compliant
REEL Emballage
ACCESSOIRES
End of Life: Final orders must be placed by 03/31/2026
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Taiyo Yuden NR8040T220M is a power shielded inductor with a wirewound construction. This compact component has an inductance rating of 22uH, offering efficient power filtering and noise suppression capabilities. With a tolerance of 20% and a maximum frequency of 100KHz, it ensures stable performance in a wide range of electronic applications. The ferrite core provides excellent magnetic properties, allowing for high current handling up to 2.2A. Additionally, the low direct current resistance (DCR) of 0.0858Ohm minimizes power losses and increases overall efficiency. The NR8040T220M comes packaged in a standard tape and reel format (3131 T/R), making it suitable for automated assembly processes.

Search Keywords: NR8040T220M

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Taiyo Yuden
Référence:
NR8040T220M
Alias/AKA:
LMNR8040T220M
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
PH
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
1000
Package Type:
REEL
Inductance:
22 uH
Type:
Power7105
Impedance:
N/A
Tolerance:
207104%
Technology:
Wirewound7103
Maximum DC Current:
2.2 A
Maximum DC Resistance:
0.0858 Ohm
Operating Temperature:
-25 to 120 °C
Packaging:
Tape and Reel
Protection Style:
Shielded7102
End of Life:
Final orders must be placed by 03/31/2026
  Different packaging options available.  See Alternatives
  End of Life: Final orders must be placed by 03/31/2026

EN STOCK: 30,050

Peut être expédié immédiatement

Commande min Quantitè: 1000

Multiple: 1000

DÉLAI DE L'USINE 7 Weeks

PRICE (USD)

QTÉ
Prix unitaire
1 000
$0.1879
3 000
$0.1779
5 000
$0.1669
8 000
$0.1660
10 000
$0.1627
25 000
$0.1613
50 000
$0.1578
100 000 +
$0.1570
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
Remplacement recommandé
LMNR8040T220M
LMNR8040T220M
VIEW PRODUCT

Tools/3D Models

ressources
