FSM4LPA
Switch Tactile OFF (ON) SPST Round Button Gull Wing 0.05A 12VDC 2.55N SMD T/R ...
DESCRIPTION
FSM4LPA is a low-profile surface-mount tactile switch from the FSM1LP series, featuring a compact 0.236" x 0.236" (6 mm x 6 mm) footprint designed for space-constrained applications. The switch utilizes copper alloy silver-clad plated contacts, a PPS case and stem, and a steel tin-plated cover, delivering robust electrical performance with a contact rating of 50 mA at 12 VDC and initial contact resistance of 100 milliohms maximum. It operates reliably across a temperature range of -20°C to +85°C with an insulation resistance of 100 megohms minimum at 100 VDC and dielectric strength of 500 VAC for 1 minute, supporting up to 100,000 mechanical cycles. The FSM4LPA is ideal for consumer electronics, industrial control panels, and portable devices where reliable tactile feedback and compact form factor are essential.
Points forts du produit:
- Switch - Mechanical
- Tactile
- Single Pole - Single Throw Configuration (Pole-Throw)
- Contact Rating = 50mA
- Operating Function = Off [On]
Mots-clés de recherche: FSM4LPA
SPÉCIFICATIONS
EN STOCK: 9 496
Peut être expédié immédiatement
Quantité minimale de commande pour qté en stock: 500
Quantité minimale de commande pour qté en rupture de stock: 500
DÉLAI DE L'USINE 19 Semaines
Prix (CAD)
Outils/Modèles 3D
ressources
Fiche technique
