102387-8 by te connectivity / amp brand
Image is representational - see mfr. specs

102387-8

TE Connectivity / AMP Brand

34 Position Rectangular Housing Connector Receptacle Black 0.100" (2.54mm) ...

Fiche technique
RoHS Compliant
Pack Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 102387-8 is a 34-position 2-row Receptacle Housing with beryllium copper contacts and crimp termination and it is used with AMPMODU socket. The Mod IV series connector provides dual cantilever contact beam with built-in anti-overstress for reliable mating. UL94V-0 Flammability rating 2.54mm Pitch spacing 250V Voltage rating 5000MΩ Insulation resistance -65 to +105°C Temperature range Rugged Applications Automotive, Portable Devices, Consumer Electronics, Gaming, Medical, Instrumentation, Test & Measurement, Industrial Automation, Telecommunications

Product Highlights:

  • Receptacle Housing
  • Wire Termination Type = Crimp
  • Number of Positions = 34
  • Housing Type = Receptacle
  • Number of Rows = Dual

Search Keywords: 1023878

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
TE Connectivity / AMP Brand
Référence:
102387-8
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
34
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
3/Contact A
Operating Temperature:
-65 to 105 °C

EN STOCK: 2,211

Peut être expédié immédiatement

Commande min Quantitè: 5

DÉLAI DE L'USINE 49 Weeks

PRICE (USD)

QTÉ
Prix unitaire
5
$5.78
25
$3.78
100
$3.68
250
$3.57
500
$3.53
1 000
$3.52
2 500
$3.50
5 000 +
$3.48
