1-1658621-0 by te connectivity / amp brand
Image is representational - see mfr. specs

1-1658621-0

TE Connectivity / AMP Brand

50 Position Rectangular Receptacle Connector IDC Gold 26-28 AWG ...

Fiche technique
RoHS Compliant
Tray Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-1658621-0 is a 50-position 2-row vertical wire-to-board Ribbon Cable Pin Header with gold-plated phosphor bronze contacts and black UL94V-0 rated thermoplastic housing. Novo receptacles offer a dual contact interface with all normal force created by metal-to-metal contact. This provides a higher degree of contact reliability. Contacts mate with 0.642mm or round posts with 6.22mm maximum and 4.45mm minimum lengths. The Novo tuning fork contact offers a military-approved design. Insulation displacement contacts for fast, economical mass terminations Contact design provides uniform latching of contacts and housing with connector cover Accepts wire size range 28 to 26AWG (0.08 to 0.15mm²), solid or stranded Snap-on strain relief and choice of pull loops available One-step termination with Novo tooling Applications Defence, Military & Aerospace

Product Highlights:

  • Connector Type = NOVO
  • Number of Positions = 50
  • Receptacle
  • Mating Polarization Method = Center & Military
  • With Mating Polarization

Search Keywords: 116586210

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
TE Connectivity / AMP Brand
Référence:
1-1658621-0
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
36
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
50
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C

EN STOCK: 6,060

Peut être expédié immédiatement

Manufacturer Stock: 13 500   Peut expédier 5/18/26

sur commande: 2 700   Peut expédier 5/25/26

Commande min Quantitè: 36

Multiple: 36

DÉLAI DE L'USINE 2 Weeks Peut expédier 5/18/26

PRICE (USD)

QTÉ
Prix unitaire
36
$2.01
108
$1.97
252
$1.91
504
$1.86
1 008
$1.85
2 520
$1.84
5 004
$1.83
7 524 +
$1.82
Emballage standard du fournisseur
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
