1-330518-1
PG RING 12-10 #10 ...
DESCRIPTION
The 1-330518-1 is a ring tongue terminal with Plasti-Grip insulation designed for 12-10 AWG solid or stranded wire applications. The terminal features a copper body with tin plating per ASTM B545 and yellow PVC insulation, with a stud hole diameter of 5.00 ±0.08 mm for #10 studs. The tongue material thickness is 0.99±0.05 mm, and the terminal accommodates wire insulation diameters of 5.08–7.62 mm. With a maximum voltage rating of 600V (1000V for fixtures or signs) and a maximum recommended operating temperature of 105°C, this terminal is suitable for electrical connections in automotive, industrial, and general wiring applications where reliable crimped connections are required.
Points forts du produit:
- Terminal Shape = Ring Tongue
- Receptacle Style = Straight
- Body Style = PLASTI-GRIP
- Barrel Type = Closed Barrel
- Wire/Cable Type = Regular Wire
Mots-clés de recherche: 13305181
SPÉCIFICATIONS
EN STOCK: 1 800
Expédition today, Saisissez la valeur du paramètre.
Quantité minimale de commande: 500
Ce modèle de message est utilisé pour informer un affilié qu'une certaine commande a été payée. La commande obtient le statut Payée lorsque le montant a été débité.: 500
DÉLAI DE L'USINE 15 Semaines
Prix (USD)
3D PDF
Product Drawing - TERMINAL, RING TONGUE, PLASTI-GRIP
Fiche technique
Product Specification - PLASTI GRIP Terminals and Splices
Instruction Sheet - LARGE EXPANSION PRODUCTS (FOR WIRE INSTULATION WITH 1/16'' AND 5/64'' WA
