1376350-2 by te connectivity / amp brand
Image is representational - see mfr. specs

1376350-2

TE Connectivity / AMP Brand

025 I/O CAP HSG ASSY 8P ...

Fiche technique
RoHS Compliant
Tube Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1376350-2 is an 8-position I/O cap housing assembly connector designed for signal circuit applications in automotive, truck, bus, and off-road environments. This connector features a 2.2 mm pitch with 0.64 mm tab width and thickness, configured in 2 rows with tin-plated interface contacts. It supports through-hole solder termination with horizontal/90° mounting orientation and operates within a temperature range of -30°C to 105°C at a nominal voltage of 12 VDC. The housing dimensions are 24.47 mm length, 14.2 mm width, and 15.5 mm profile height from PCB, making it suitable for wire-to-wire connections in demanding vehicular applications requiring reliable signal transmission.

Product Highlights:

  • Housing Assembly
  • Receptacle (Cap)
  • Receptacle Configuration = 025
  • Number of Positions = 8
  • Mount = Printed Circuit Board

Search Keywords: 13763502

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
TE Connectivity / AMP Brand
Référence:
1376350-2
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
JP
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
32
Package Type:
Tube
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
RCP
Mounting:
Through Hole
Pitch:
2.2 mm
Number of Contacts:
8
Maximum Voltage Rating:
12 VDC
Maximum Current Rating:
N/A
Termination Method:
Solder
Operating Temperature:
-30 to 105 °C

EN STOCK: 8,796

Peut être expédié immédiatement

Quantité minimale de commande pour qté en stock: 64

Quantité minimale de commande pour qté en rupture de stock: 64

Multiple: 32

DÉLAI DE L'USINE 18 Weeks

PRICE (USD)

QTÉ
Prix unitaire
64
$2.60
100
$2.59
280
$2.58
560
$1.59
840
$1.26
1 120 +
$1.23
Log in for special pricing Click for Quote Price Match Request
