1432772-1
TE Connectivity / AMP BrandPower Relay 12VDC 40A SPST-NO(26.5mm 31.6mm 38.4mm) Plug-In ...
DESCRIPTION
1432772-1 is an electromechanical relay featuring a 1 Form A (SPST) contact arrangement for high-current switching applications. It operates with a maximum operate voltage of 7.8 VDC and a minimum release voltage of 1.2 VDC, with a coil resistance of 90 Ohms ±10%. The relay supports a maximum continuous current of 40A at 23°C (35A at 85°C) and features AgSnO (Silver Tin-Oxide) contact material with a millivolt drop of 200mV at 35A. Operating over a temperature range of -40°C to +85°C, it offers an expected electrical life of 100,000 operations at 40A, 14 VDC resistive load and a mechanical life of 10 million operations without contact load. This relay is suitable for industrial and commercial power switching applications requiring reliable high-current performance.
Search Keywords: 14327721
SPÉCIFICATION
EN STOCK: 5 089
Peut être expédié immédiatement
Commande min Quantitè: 2
Prix (USD)
Outils/Modèles 3D
ressources
Fiche technique
