1-966144-0
FER,WIRE,DBL,PL SLV,4.00/12,L12,GREY,LP ...
DESCRIPTION
1-966144-0 is a double wire ferrule with plastic sleeve designed for connecting two 4.00 mm² flexible conductors with screw or spring clamps. The ferrule features a copper sleeve with galvanic tin plating and a polypropylene plastic collar rated up to +120°C, manufactured according to DIN 46228 Part 4 specifications. Key dimensions include an overall length (A) of 23.0 mm, a width (B) of 12.0 mm, a sleeve thickness (C) of 3.70 mm, and a total height (D) of 8.8 mm with an internal dimension (E) of 4.9 mm. The product is supplied in strip form with a strip length of 14.0 mm and is packaged in quantities of 100 units. This ferrule is ideal for automotive powertrain systems, safety and security systems, and other applications requiring gas-tight, color-coded insulated connections that protect crimped connections from contact and corrosion.
Points forts du produit:
- Tubular End Sleeve
- Wire Range = (2) 4.00² [(2) 11.5-11] mm [AWG]
- Double Wire
- Strip Length = 14.00 mm
- Color = Gray
Mots-clés de recherche: 19661440
SPÉCIFICATIONS
EN STOCK: 14 689
Peut être expédié immédiatement
Quantité minimale de commande: 100
Ce modèle de message est utilisé pour informer un affilié qu'une certaine commande a été payée. La commande obtient le statut Payée lorsque le montant a été débité.: 100
DÉLAI DE L'USINE 15 Semaines
3D PDF
Product Drawing - WIRE FERRULE WITH PLASTIC SLEEVE, DOUBLE CONDUCTOR, LOOSE PIECE
Fiche technique
Agency Approval Document - INSULATED FERRULES CERTIFICATE
