1996771-1
The 1996771-1 is a straight, panel-mount SMPM RF cable jack connector with a 50 Ω impedance. ...
DESCRIPTION
The 1996771-1 is a straight, single-port SMPM RF cable jack connector designed for panel mounting. It features a characteristic impedance of 50 Ω and supports an operating frequency of up to 26 GHz. This connector is constructed with a gold-plated beryllium copper body and is intended for termination to .047" semi-rigid or flexible coaxial cables via soldering. With a wide operating temperature range of -65°C to 165°C and a push-on coupling mechanism, it is suitable for high-reliability applications, including those compliant with VITA 67 standards.
Mots-clés de recherche: 19967711
SPÉCIFICATIONS
EN STOCK: 209
Peut être expédié immédiatement
sur commande:
600
Peut expédier 8/26/26
sur commande:
1 200
Peut expédier 9/14/26
Quantité minimale de commande pour qté en rupture de stock: 70
DÉLAI DE L'USINE 40 Semaines
Prix (USD)
3D PDF
ressources
Product Drawing - SMPM STRAIGHT CABLE JACK (F) FLOATING PANEL MOUNT - FOR USE WITH .047 DIA. AND S
Fiche technique
Product Specification - Modular, High Density, RF Connection System
Instruction Sheet - SMPM Floating Panel Mount, Cable Jacks (Direct Solder Attachment) 1996390-1, 1996771-1
