DESCRIPTION
The 2005390-6 is a 24-position MULTILOCK connector housing designed for wire-to-wire connections with male terminals in automotive applications. It features a rectangular shape with 3 rows of positions, a 2.2 mm centerline pitch, and supports mixed hybrid connector configurations for both power and signal transmission. The housing is constructed from PBT material in natural color, with contact sizes of 0.63 mm, 2.3 mm, and 2.8 mm tab widths, and operates at a nominal voltage of 12 V. With dimensions of 39.5 mm width, 40.2 mm length, and 26.65 mm height, and row-to-row spacing of 3 mm and 10 mm, this connector is cable-mounted and serviceable. It is compliant with EU RoHS Directive 2011/65/EU and EU ELV Directive 2000/53/EC, making it suitable for automotive harness assemblies requiring reliable power and signal distribution.
Mots-clés de recherche: 20053906
SPÉCIFICATIONS
EN STOCK: 1 240
Peut être expédié immédiatement
Quantité minimale de commande pour qté en stock: 150
Quantité minimale de commande pour qté en rupture de stock: 150
DÉLAI DE L'USINE 18 Semaines
3D PDF
Product Drawing - JPT SEALED 3P PLUG ASS'Y
Fiche technique
Product Specification - JPT SEALED 2P, 3P PLUG ASS'Y
