DESCRIPTION
350715-4 is a 6-circuit Universal MATE-N-LOK pin header connector designed for wire-to-board power circuit applications. It features a matrix configuration with a 0.550 inch (13.97 mm) A dimension, UL94V-0 nylon housing material with a 120°C temperature rating, and pre-tin duplex finish plating (0.000030 inch minimum gold in mating area with matte tin on solder tail over 0.000050 inch minimum nickel underplate). The connector includes a standard tail option for 0.062 inch thick PCBs and a long tail option for 0.125 inch thick PCBs, with a polarizing feature to ensure correct mating. This connector is commonly used in power distribution circuits for home appliances and industrial equipment, offering reliable electrical connections with secure locking mechanisms and protection against wire tangling.
Points forts du produit:
- Housing
- Universal MATE-N-LOK
- Not CompactPCI
- 6.35 x 6.35 mm Centerline, Matrix
- Number of Circuits = 6
Search Keywords: 3507154
SPÉCIFICATION
EN STOCK: 369
Peut être expédié immédiatement
sur commande:
1 000
Peut expédier 9/9/26
Commande min Quantitè: 50
DÉLAI DE L'USINE 14 Weeks
3D PDF
Product Drawing - PLUG, 6 CIRCUIT, UNIVERSAL MATE-N-LOK(TM)
Fiche technique
Product Specification - Product Specification - Universal MATE-N-LOK Connectors
Instruction Sheet - Universal, Commercial, and .140 MATE-N-LOK Contact and Housing Selection Charts
