3-641215-2 by te connectivity / amp brand
Image non contractuelle - consultez les spécifications du fabricant

3-641215-2

TE Connectivity / AMP Brand

Wire-To-Board Connector - 2.54 mm - 2 Contacts - Header - MTA-100 Series - Through Hole - 1 Rows. ...

Fiche technique
RoHS Compliant
BAG Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

The MTA-100 series MTA Connector System is a wire-to-board system based on insulation displacement contact (IDC) technology. Mass termination of wires provides the lowest applied cost because it drastically reduces the labour content of virtually any cable or harness assembly required. MTA 100 connectors have contacts in a single row on 0.100-inch (2.54mm) centre. The design features wire feed-through capability for daisy-chain applications. Insulation displacement contacts (IDC) are used to terminate a wide range of conductor sizes. Ribbon cable can also be terminated when the appropriate receptacle assembly and strain relief cover are used.

Points forts du produit:

  • MTA-100 Connectors
  • Number of Positions = 2
  • Mating Type = Header
  • Wire-to-Board Application
  • 2.54 mm Contact Centerline Spacing

Search Keywords: 36412152

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
TE Connectivity / AMP Brand
Référence:
3-641215-2
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000
Package Type:
BAG
Type:
Wire to Board
Orientation du corps:
Straight
Genre:
HDR
Montage:
Through Hole
Pas:
2.54 mm
Nombre de contacts:
2
Tension maximale nominale:
250 VAC
Courant nominal maximal:
5/Contact A
Méthode de terminaison:
Solder
Température de fonctionnement:
-55 to 105 °C
  Possible Replacement options available.  See Alternatives

EN STOCK: 0

sur commande: 3 756   Peut expédier 8/28/26

Commande min Quantitè: 50

DÉLAI DE L'USINE 13 Weeks

Prix (USD)

QTÉ
Prix unitaire
50
$0.5698
500
$0.3178
1 000
$0.3121
2 500
$0.3015
5 000
$0.2964
10 000
$0.2957
15 000
$0.2950
25 000 +
$0.2942
Emballage standard du fournisseur
