5188398-1
The 5188398-1 is a 110-position, 5-row, Type A vertical mount male plug from the Z-PACK 2mm Hard Metric connector system. ...
DESCRIPTION
The 5188398-1 is a Type A male plug connector from the Z-PACK 2mm Hard Metric (HM) family. It features 110 signal contact positions arranged in five rows (A, B, C, D, E) and is designed for a vertical PCB mounting angle. The connector's phosphor bronze contacts have gold (30 µin) over nickel plating in the mating area for reliable connections, while the housing is constructed from glass-filled polyester. This standard crosstalk version has a module length of 50.00 mm and incorporates guide lugs for mating polarization. It is intended for fixed board-mount applications requiring a high-density, 2mm pitch interface.
Mots-clés de recherche: 51883981
SPÉCIFICATIONS
EN STOCK: 529
Peut être expédié immédiatement
Quantité minimale de commande pour qté en stock: 5
Quantité minimale de commande pour qté en rupture de stock: 113
DÉLAI DE L'USINE 10 Semaines
3D PDF
Product Drawing - MALE ASSEMBLY, Z-PACK 2mm HM, TYPE A
Fiche technique
Product Specification - Z-Pack 2 mm HM CONNECTORS
