5747299-2 by te connectivity / amp brand
Image non contractuelle - consultez les spécifications du fabricant

5747299-2

TE Connectivity / AMP Brand

D Sub Connector - DB15 - 15 Contacts - Receptacle - Solder - DA - AMPLIMITE HD-20 Series - Steel Body. ...

Fiche technique
RoHS Compliant
TUBE Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

This 5747299-2 DVI connector from TE Connectivity is ideal for all your serial communication needs. It has a straight body orientation. It has a maximum voltage rating of 250 VDC|250VAC. Its pitch is 2.74 mm. This socket type connector's 15 contacts that are made out of phosphor bronze and plated with gold over nickel. This 2-row connector has a single port. 5747299-2 is housed in polyester. In order to ensure parts aren't damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This DVI connector has an operating temperature of -55 to 105 °C. This product is 39.12 mm long, 12.16 mm tall and 12.55 mm deep. Its 15 terminals use the solder termination method.

Points forts du produit:

  • Number of Positions = 15
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • Without Mating Connector Lock

Search Keywords: 57472992

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
TE Connectivity / AMP Brand
Référence:
5747299-2
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
13
Package Type:
TUBE
Type:
D-Subminiature
Orientation du corps:
Straight
Montage:
Through Hole
Genre:
SKT
Méthode de terminaison:
Solder
Taille de la coque:
2
Nombre de contacts:
15
Placage des contacts:
Gold over Nickel
Température de fonctionnement:
-55 to 105 °C

EN STOCK: 583

Peut être expédié immédiatement

sur commande: 819   Peut expédier 2/22/27

Commande min Quantitè: 13

Multiple: 13

DÉLAI DE L'USINE 30 Weeks

Prix (USD)

QTÉ
Prix unitaire
13
$4.555
52
$4.478
104
$4.404
260
$4.276
507
$4.221
1 001 +
$4.210
Emballage standard du fournisseur
Log in for special pricing Cliquez pour demander un devis Price Match Request
