796634-3 by te connectivity / amp brand
Image is representational - see mfr. specs

796634-3

TE Connectivity / AMP Brand

3 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line) ...

Fiche technique
RoHS Compliant
Box Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 796634-3 is a 3-position 1 row 5.08mm pluggable Terminal Block with tin-plated phosphor bronze contact, nickel-plated brass screw, polyamide 6.6 green housing. Plug connector, right angle mounting, through hole contact mount, screw wire connection method, M3 screw and 30 to 16AWG wire range. Side wire entry angle Number of Positions: 3 Position Pitch: 5.08 mm Connection Method: Screw Current Rating: 15 A Voltage Rating: 300 V Wire Gauge Range: 30 AWG to 12 AWG Color: Green Contact Plating: Tin Housing Material: Polyamide (PA) Mounting Angle: Right Applications Industrial

Product Highlights:

  • Connector
  • Connector Type = Plug
  • Housing Color = Green
  • Not Stacked
  • Without Threaded Flange

Search Keywords: 7966343

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
TE Connectivity / AMP Brand
Référence:
796634-3
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
IT
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Box
Type:
Eurostyle Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
3
Maximum Voltage Rating:
300 VAC
Maximum Current Rating:
15/Contact A
Wire Size:
12-30 AWG
Operating Temperature:
N/A

EN STOCK: 26,992

Peut être expédié immédiatement

Commande min Quantitè: 10

DÉLAI DE L'USINE 11 Weeks

PRICE (USD)

QTÉ
Prix unitaire
10
$3.028
50
$1.386
200
$1.289
400
$1.266
600
$0.904
1 000
$0.902
2 600
$0.900
5 000 +
$0.897
Emballage standard du fournisseur
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
