JMACD-26XM

TE Connectivity / CII Brand

Electromechanical Relay 26.5VDC 1.56KOhm 1A DPDT (9.4x10.29x7.11)mm THT Military Relay ...

Fiche technique
RoHS Compliant
Pack Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

JMACD-26XM is a Type JMAD electromagnetic relay designed for high-reliability military and aerospace applications. It features a coil resistance of 1560 ohms ±10% at 25°C, with a nominal voltage of 26.5 VDC and must operate voltage of 14.2 VDC. The relay offers fast switching performance with an operate time of 2 ms maximum and release time of 4 ms maximum. Environmental specifications include vibration resistance from 10 CPS to 3000 CPS at 30 g's, shock resistance of 75 g's for 6 ms duration, and an operating temperature range of -65°C to +125°C. The contact rating supports low level to 28 VDC resistive loads with 100,000 operations, making it suitable for demanding signal switching applications in harsh environments.

Product Highlights:

  • MAD TO-5 Relay Series
  • Input Voltage = 26.5 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 1 Amps.
  • Non Polarized, Monostable Coil Magnetic System

Search Keywords: JMACD26XM

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
TE Connectivity / CII Brand
Référence:
JMACD-26XM
Alias/AKA:
M39016/15-081M, 1-1617122-2
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
IN
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
Military Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
26.5 V
Maximum Current Rating:
1 A
Coil Current:
16.99 mA
Coil Resistance:
1.56 KOhm
Mounting:
Through Hole
Operating Temperature:
-65 to 125 °C
Termination Style:
PC Pin

EN STOCK: 48

Peut être expédié immédiatement

sur commande: 120   Peut expédier 9/2/26

DÉLAI DE L'USINE 18 Weeks

PRICE (USD)

QTÉ
Prix unitaire
1
$63.13
5
$61.78
10
$60.57
25
$60.42
50
$59.96
100
$59.36
250 +
$58.02
Log in for special pricing Click for Quote Price Match Request
