1EB3 by te connectivity / corcom brand
Image is representational - see mfr. specs

1EB3

TE Connectivity / Corcom Brand

Power Line Filter General Purpose RFI 50Hz/60Hz 1A 250VAC Wire Lead Flange Mount ...

Fiche technique
RoHS Compliant
Pack Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1EB3 is a general-purpose RFI power line filter designed for high impedance loads at low current, featuring low leakage current characteristics suitable for portable equipment and non-patient medical devices. It provides maximum leakage current of 0.21 mA at 120 VAC 60 Hz and 0.36 mA at 250 VAC 50 Hz, with a rated voltage of 250 VAC and operating frequency of 50/60 Hz. The filter is equipped with wire leads (AWG18, 4.0 inches minimum length) for flexible installation and meets UL, CSA, and VDE safety standards. It operates reliably across an ambient temperature range of -10°C to +40°C at rated current, with derating capability for higher temperatures. The 1EB3 is ideal for applications requiring compact size, low cost, and compliance with VDE low leakage current requirements for portable and medical equipment.

Product Highlights:

  • Filter - EMI/RFI
  • Filter Type = Power Line
  • B (1-30 Amp) Series
  • General Purpose Application
  • Mount Style = Flanged

Search Keywords: 1EB3

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
TE Connectivity / Corcom Brand
Référence:
1EB3
Alias/AKA:
6609020-2
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8548000000
COO:
US
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
56
Package Type:
Pack
Mounting:
Flange Mount
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1 A
Operating Frequency:
50,60 Hz
Operating Temperature:
-10 to 40 °C
Dimension:
64.3 x 16.8 mm

EN STOCK: 235

Peut être expédié immédiatement

Quantité minimale de commande pour qté en stock: 5

Quantité minimale de commande pour qté en rupture de stock: 42

DÉLAI DE L'USINE 17 Weeks

PRICE (USD)

QTÉ
Prix unitaire
5
$31.59
10
$31.52
25
$31.44
42
$31.36
84
$19.30
126
$15.27
168 +
$14.98
