DTM04-3P-E004 by te connectivity / deutsch automotive
Image non contractuelle - consultez les spécifications du fabricant

DTM04-3P-E004

TE Connectivity / Deutsch Automotive

Conn Housing RCP 3 POS Crimp ST Cable Mount Black Box Automotive ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

The DTM04-3P-E004 is a 3-position sealed receptacle connector from the DT Family series designed for industrial and commercial transportation applications. This connector is specifically engineered for J1939 3-wire CAN (Controller Area Network) systems, accommodating CAN_HI, CAN_LO, and shield wires for serial data communications between Electronic Control Units (ECUs). The receptacle features a welded flange with shrink boot adapter in black finish, providing enhanced environmental protection and improved aesthetics. It utilizes size 16 gold-plated contacts (pins or sockets) and is compatible with standard wire sealing ranges of 0.088–0.145 inches (2.23–3.68 mm) for 14–20 AWG wire. The connector is rated to operate in harsh environments from -70°F to +225°F (-56°C to +107°C) and supports network termination with optional molded-in 120O resistors. Common applications include vehicle electrical systems, agricultural equipment, construction machinery, and other heavy-duty transportation platforms requiring reliable CAN bus connectivity.

Search Keywords: DTM043PE004

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
TE Connectivity / Deutsch Automotive
Référence:
DTM04-3P-E004
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Montage:
Cable Mount3496
Orientation du corps:
Straight3485
Genre:
RCP3489
Méthode de terminaison:
Crimp3503
Nombre de contacts:
3
Tension maximale nominale:
2503494VDC
Courant nominal maximal:
7.5/Contact A
Température de fonctionnement:
-55 to 125 °C

EN STOCK: 1 132

Peut être expédié immédiatement

Commande min Quantitè: 25

DÉLAI DE L'USINE 13 Weeks

Prix (USD)

QTÉ
Prix unitaire
25
$1.84
100
$1.63
250
$1.51
500
$1.43
1 000
$1.37
2 500
$1.29
5 000
$1.28
7 500 +
$1.27
Log in for special pricing Cliquez pour demander un devis Price Match Request
