HDP26-24-18PE by te connectivity / deutsch automotive
Image is representational - see mfr. specs

HDP26-24-18PE

TE Connectivity / Deutsch Automotive

PLG, 18P, BLK, E, 8/12/16, P ...

Fiche technique
RoHS Compliant
Tray Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / DEUTSCH Automotive HDP26-24-18PE is a premium plug designed for demanding automotive applications. With a robust 18-position configuration, this connector is engineered to provide reliable performance in harsh environments. The black, environmentally-sealed plug is compatible with contact sizes 8, 12, and 16, ensuring versatile connectivity options for various electrical systems. Its durable construction offers excellent resistance to vibration, moisture, and extreme temperatures, making it ideal for use in heavy-duty vehicles, off-road machinery, and other high-stress situations. The HDP26-24-18PE is a trusted choice for professionals seeking high-quality, dependable connectors that deliver exceptional service life and performance.

Search Keywords: HDP262418PE

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
TE Connectivity / Deutsch Automotive
Référence:
HDP26-24-18PE
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Package Type:
Tray
Serviceable:
Yes
Connector Position Assurance Capable:
No
Degree of Protection:
IP67
UL Flammability Rating:
20mm Flame Test per Standard UL-94
Connector & Housing Type:
Housing for Male Terminals
Terminal Position Assurance:
No
Strain Relief:
Add By Accessory
Number of Positions:
18
Connector System:
Wire-to-Wire
Sealable:
Yes
Primary Product Color:
Black
Primary Locking Feature:
Contact Retainer
Cable Exit Angle:
180°
Packaging Method:
Box
Blank Cavity Position:
0
Operating Temperature (Max):
125 °C, 257 °F
Product Width:
1.95 in, 49.53 mm
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Operating Voltage:
250 VAC, 250 VDC
Mating Pin Diameter:
.063 in, .094 in, .142 in, 1.59 mm, 2.39 mm, 3.61 mm
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Product Length:
1.521 in, 38.63 mm
Contact Current Rating (Max):
13 A, 25 A, 60 A
Connector & Contact Terminates To:
Wire & Cable
Circuit Application:
Power & Signal
Mating Alignment:
With
Contact Type:
Pin
Mating Alignment Type:
Guide Slot
Connector Height:
1.95 in, 49.53 mm
Connector Shape:
Circular
Contact Size:
Size 12 , Size 16 , Size 8
Housing Material:
PA GF
Connector Mounting Type:
Cable Mount (Free-Hanging)

EN STOCK: 197

Peut être expédié immédiatement

Commande min Quantitè: 5

DÉLAI DE L'USINE 13 Weeks

PRICE (USD)

QTÉ
Prix unitaire
5
$16.38
40
$14.17
80
$13.77
120
$13.01
280
$12.67
520
$12.64
1 000 +
$12.49
