GRF303-5 by teledyne relays
Image is representational - see mfr. specs

GRF303-5

Teledyne Relays

Electromechanical Relay - 5VDC - 100Ohm - 1A - DPDT - (9.52x10.41x10.6)mm - SMD Signal Relay. ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRF303-5 ultraminiature GRF303 relays are designed to provide a practical surface-mount solution with improved RF signal repeatability over the frequency range. GRF303 relays feature a unique ground shield that isolates and shields each lead to ensure excellent contact-tocontact and pole-to-pole isolation. The GRF303 version with the improved ground connections can push the performance up into the 10Gbps data rates for digital signal integrity applications. This ground shield provides a ground interface that results in improved high-frequency performance as well as parametric repeatability. The GRF300 extend performance advantages over similar RF devices that simply offer formed leads for surface mounting. These relays are engineered for use in RF attenuator, RF switch matrices, ATE and other applications that require dependable high frequency signal fidelity and performance.

Search Keywords: GRF3035

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Teledyne Relays
Référence:
GRF303-5
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
MX
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Surface Mount
Pin Count:
8
Operating Temperature:
-55 to 85 °C
Dimension:
9.52 x 10.41 x 10.6 mm
Termination Style:
N/A

EN STOCK: 32

Peut être expédié immédiatement

sur commande: 684   Peut expédier 6/1/26
sur commande: 800   Peut expédier 6/29/26
sur commande: 1 500   Peut expédier 11/16/26

DÉLAI DE L'USINE 31 Weeks

PRICE (USD)

QTÉ
Prix unitaire
1
$141.84
5
$131.05
10
$119.67
20
$118.04
50
$110.67
100 +
$110.40
Emballage standard du fournisseur
