FS36-065-C2 by triad magnetics
Image is representational - see mfr. specs

FS36-065-C2

Triad Magnetics

The FS36-065-C2 is a Class 3 split bobbin transformer featuring a series/parallel primary and dual secondary windings. ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The FS36-065-C2 is a 2.5VA Class 3 transformer with a versatile split bobbin design. Its primary winding can be configured for either a 115V parallel input or a 230V series input. The device provides two independent secondary windings, each rated for 18.0V at 0.065A, which can be connected in series for higher voltage or in parallel for higher current. The split bobbin construction provides low capacitive coupling and high isolation, eliminating the need for an electrostatic shield. With a wide operating temperature range of -40°C to 105°C and inherent power limitation that requires no fusing, this transformer is ideal for a variety of general-purpose, safety-isolating applications.

Search Keywords: FS36065C2

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Triad Magnetics
Référence:
FS36-065-C2
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8504314035
COO:
PH
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Primary Configuration:
Dual
Primary Side Voltage:
230,115 V
Secondary Configuration:
Dual
Secondary Side Voltage:
36,18 V
Secondary Side Current:
65,130 mA
Power Rating:
2.5 VA
Mounting:
Through Hole
Dimension:
35.51 x 30.51 x 32 mm

EN STOCK: 0

Commande min Quantitè: 10

Multiple: 10

DÉLAI DE L'USINE 18 Weeks

PRICE (USD)

QTÉ
Prix unitaire
10
$8.64
50
$5.96
100
$5.48
250
$5.46
500
$5.33
1 000
$5.30
2 500
$5.27
5 000 +
$5.25
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
