260-4T5E by wakefield
Image is representational - see mfr. specs

260-4T5E

Wakefield

The 260-4T5E is an epoxy-insulated cup clip heat sink with a tapped base, designed for TO-5 case style semiconductors. ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 260-4T5E is an epoxy-insulated cup clip from the 260 Series, designed to provide thermal management for TO-5 case style semiconductors. It features a tapped base with a #4-40 UNC thread and a depth of 0.093 inches. Constructed with a beryllium copper cup and a brass base, both finished with black ebonol 'C', this clip provides a thermal resistance of 14° C/W. The epoxy insulation offers a breakdown voltage of 500 VAC, making this component suitable for applications requiring reliable heat dissipation and electrical isolation in a continuous operating temperature range of -73°C to +149°C.

Search Keywords: 2604T5E

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Wakefield
Référence:
260-4T5E
Alias/AKA:
2604T5E
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8473309100
COO:
US
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Device Cooled:
TO-5
Attachment Method:
Clip
Dimension:
9.4 x 9.7 mm
Thermal Resistance:
14 °C/W
Finish:
Black Ebonol

EN STOCK: 117

Peut être expédié immédiatement

DÉLAI DE L'USINE 12 Weeks

PRICE (USD)

QTÉ
Prix unitaire
1
$27.77
5
$22.86
10
$18.79
25
$18.33
50
$17.75
100
$17.57
300 +
$16.67
Emballage standard du fournisseur
