25.602.2453.0 by wieland electric
Image is representational - see mfr. specs

25.602.2453.0

Wieland Electric

The 25.602.2453.0 is a 4-pole, pluggable PC board connector with a 5.00 mm spacing. ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 25.602.2453.0 is a 4-pole, gray, pluggable PC board connector designed for secure wire-to-board connections. It features a 5.00 mm spacing and a plug-in orientation at 90° to the wire entry. This connector is rated for 8 A (VDE) and accepts a wire range of 0.14-4.0 mm² for solid conductors or 0.14-2.5 mm² for fine stranded conductors. Constructed with a UL 94-V-0 rated polycarbonate housing, it is suitable for various industrial and commercial electronic applications requiring reliable, pluggable connections.

Search Keywords: 2560224530

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Wieland Electric
Référence:
25.602.2453.0
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536690090
COO:
DE
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
PC Terminal Block
Body Orientation:
Straight
Gender:
F
Mounting:
Cable Mount
Pitch:
5 mm
Number of Contacts:
4
Maximum Voltage Rating:
300 V
Maximum Current Rating:
15 A
Termination Method:
Screw
Operating Temperature:
N/A

EN STOCK: 4,155

Peut être expédié immédiatement

Commande min Quantitè: 50

Multiple: 50

DÉLAI DE L'USINE 3 Weeks

PRICE (USD)

QTÉ
Prix unitaire
50
$1.073
250
$0.746
500
$0.692
1 000
$0.660
2 500
$0.623
5 000
$0.622
7 500
$0.620
10 000 +
$0.619
Emballage standard du fournisseur
