GS100101 by zf electronic systems
Image non contractuelle - consultez les spécifications du fabricant

GS100101

ZF Electronic Systems

Hall Effect Sensor 20mA 9V/12V/15V/18V 4-Pin ...

Fiche technique
RoHS Compliant
BOX Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantie du certificat de conformité

DESCRIPTION

GS100101 is a Hall Effect gear tooth speed sensor designed for ferrous edge detection and near-zero speed sensing without power-up recognition. The sensor features a current sinking output that requires an external pull-up resistor, with an adjustable stainless steel housing and M12-1 Class 6g thread connector. It operates across a voltage range of 5–24 VDC with a maximum supply current of 6 mA, output saturation voltage of 400 mV, and output current capability of 20 mA, while maintaining immunity to rotational alignment and ESD protection up to 4 kV direct contact. The sensor is rated for operating temperatures from -40°C to +125°C and features fast output switching with rise and fall times of 5 µs. Common applications include CNC machine tools, transmission speed monitoring, and industrial feedback control systems where reliable speed detection is critical.

Points forts du produit:

  • Sense Motion of Ferrous Geartooth Targets
  • Near-Zero Speed Sensing Capability
  • Immune from Hostile Environments
  • Not Subject to Rotational Orientation
  • High-Speed Capability
  • Sinking (Open Collector) Output
  • Reverse Battery Protection to -24Vdc
  • Wide Operating and Storage Temperature Range
  • M12 Integral Connector Meets IEC60947 - 5 - 2
  • Meet all IEC (International Electrotechnical Commission) Requirements for Heavy Industrial Environments, Assuring Immunity from:
    • Electrostatic Discharge
    • Electrical Transients
    • Radiated Electric Field
    • Conducted Energy
    • Magnetic Field Energy

Search Keywords: GS100101

SPÉCIFICATION

Attribut du produit
Valeur de l'attribut
Sélectionner un attribut
Produits trouvés : 0
fournisseur:
ZF Electronic Systems
Référence:
GS100101
Unité de mesure:
Par Each
RoHS:
Yes
HTS:
8543704000
COO:
MX
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
BOX
Type magnétique:
Unipolar
Courant de sortie maximal:
20 mA
Montage:
Screw
Type de sortie:
Sink
Pilote de Sortie:
NPN
Type de produit:
Digital
Dimension:
65.5mm x 12mm dia
Tension d'alimentation de fonctionnement typique:
5 to 24 V
Type de terminaison:
Connector
Température de fonctionnement:
-40 to 125 °C

EN STOCK: 0

Quantité minimale de commande pour qté en rupture de stock: 250

DÉLAI DE L'USINE 20 Weeks

Prix (USD)

QTÉ
Prix unitaire
250
$130.88
500
$66.85
750
$45.51
1 000 +
$44.60
Log in for special pricing Cliquez pour demander un devis Price Match Request
