6000-3R3M-RC by bourns
Image is representational - see mfr. specs

6000-3R3M-RC

Bourns

RF Choke Bobbin Core 3.3uH 20% 7.96MHz 20Q-Factor Ferrite 5.5A 25mOhm DCR RDL ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 6000-3R3M-RC is a radial lead RF choke designed for high-frequency filtering and signal conditioning in RF and analog circuits. It features a ferrite bobbin core with low core loss at frequency, delivering 3.3 µH inductance at 1 kHz with a quality factor (Q) of 20 at 7.96 MHz. The component exhibits a self-resonant frequency (SRF) of 79 MHz, a DC resistance of 0.025 O, and supports a maximum DC current of 5.5 A before experiencing a 5% inductance drop. The winding is covered with shrink tubing and features fixed lead spacing for reliable assembly and consistent performance. Operating across a temperature range of -55°C to +105°C, this choke is ideal for RF filtering, impedance matching, and EMI suppression in communication systems, power supplies, and industrial RF applications where high reliability and efficiency are required.

Search Keywords: 60003R3MRC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
6000-3R3M-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BOX
Inductance:
3.3 uH
Type:
RF Choke
Impedance:
N/A
Lead Pitch:
5 mm
Tolerance:
20 %
Technology:
Bobbin Core
Maximum DC Resistance:
25 mOhm
Maximum DC Current:
5.5 A
Protection Style:
N/A
Packaging:
N/A

IN STOCK: 1,600

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
100
$0.5408
500
$0.4933
1,000
$0.4609
2,500
$0.4214
5,000
$0.4203
7,500
$0.4193
10,000
$0.4182
15,000 +
$0.4172
Suppliers Standard Package
