320.02E11.08BLU by e-switch
Image is representational - see mfr. specs

320.02E11.08BLU

E-Switch

Tactile Switch - SPST NO - 50VDC - 25mA - 135 (+/-) 50 gf - Blue Button - Through Hole ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 320.02E11.08BLU is an SPST (Single Pole Single Throw) tactile pushbutton switch featuring a blue cap and designed for standard PCB mounting applications. The switch is rated for 25 mA at 50 VDC and has an operating force of 135±50 gF with a travel to make of 0.7 mm, providing reliable tactile feedback for user input. The device features a 2.54 mm pitch PCB pin spacing with Ø1.22 mm PCB pins and Ø1.00 mm alignment pins, ensuring precise positioning on standard circuit boards. The body dimensions are 10.30 mm square with a cap diameter of Ø11.9 mm, and the terminal dimensions are 5.08 × 5.08 × 2.39 mm with 1.00 × 0.40 mm typical terminal cross-section. This switch is commonly used in consumer electronics, industrial control panels, and embedded systems where compact, reliable momentary switching is required.

Search Keywords: 32002E1108BLU

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
E-Switch
Référence:
320.02E11.08BLU
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
TW
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
162
Dimension:
12.4mm x 12.4mm x 14.413763mm
Mounting:
Through Hole13759
Pole Throw Configuration:
SPST13761
Switch Configuration:
N.O.13768
Actuator Style:
Round Button13737
Contact Rating @ Voltage:
0.02513752A@50VDC
Body Orientation:
Straight13740
Seal Location:
N/A

EN STOCK: 327

Peut être expédié immédiatement

Quantité minimale de commande pour qté en stock: 5

Quantité minimale de commande pour qté en rupture de stock: 648

DÉLAI DE L'USINE 14 Weeks

PRICE (USD)

QTÉ
Prix unitaire
5
$8.66
100
$6.39
250
$5.80
500
$5.54
648
$5.52
1 296
$5.51
1 944
$5.50
2 592 +
$5.48
