M22-7130342 by harwin
Image is representational - see mfr. specs

M22-7130342

Harwin

The M22-7130342 is a 2mm pitch square pin connector from the M22 series designed for board-to-board interconnections. ...

Fiche technique
RoHS Compliant
Emballage
ACCESSOIRES
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The M22-7130342 is a board-to-board connector in the M22 series, featuring a 2mm pitch for compact designs. It has a maximum current rating of 2A per contact and a contact resistance of 20mΩ maximum. This connector is rated for 300 mating cycles and functions reliably across an operating temperature range of -40°C to +105°C. Key mechanical characteristics include a maximum insertion force of 2.0N, a minimum withdrawal force of 0.2N, and a contact retention force of 4.9N per contact, ensuring a secure and durable connection in various electronic applications.

Search Keywords: M227130342

SPÉCIFICATION

Product Attribute
Attribute Value
Select Attribute
Products found: 0
fournisseur:
Harwin
Référence:
M22-7130342
Unité de mesure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Référence: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
188

EN STOCK: 376

Peut être expédié immédiatement

Commande min Quantitè: 188

Multiple: 188

DÉLAI DE L'USINE 12 Weeks

PRICE (USD)

QTÉ
Prix unitaire
188
$0.823
376
$0.786
1 128
$0.714
2 632
$0.681
5 076
$0.642
7 520
$0.641
10 152
$0.624
15 040 +
$0.622
Emballage standard du fournisseur
Log in for special pricing Click for Quote Price Match Request
